EVO392FL

Evo392fl

DISCONTINUO

Source
392x0,25W Warm White + Cold White LEDs
IP rating
 IP20
Weight
7kg / 15.43lbs

Key Features

  • 392 LEDs (60mA), to achieve brightness of 4x55 fluorescent fixtures
  • Available in Tungsten (3100 K) and DaYlight (5600K) Color temperature variants
  • No need for dimmers nor lamp replacement, LED lifespan >50.000h
  • Flicker-free for cameras, TV-studios friendly
  • No UV/IR emissions
  • Wide accessory range available

EVO392FL is a LED projector engineered to exceed conventional fluorescent tube lights (4x55W) in performance and power, creating a real opportunity to replace traditional equipment with LED light sources. EVO392FL is a projector engineered and developed for professional use in movies, television and photographic sets, implementing new possibilities as calibration of white colour temperature via the variable source (WW + CW).
EVO392FL is available in Tungsten (3100K) and Daylight version (5600K) reproducing the projection uniformity and dimmer linearity of conventional projectors, as well as same usage operations making it a user-friendly projector for technical staff.

Read less
EVO392FL is a LED projector engineered to exceed conventional fluorescent tube lights (4x55W) in performance and power, creating a real opportunity to replace traditional equipment with LED light sour...

Versions

Code Col. Temperature
EVO392FLDY
EVO392FLDY DISCONTINUO
5600K
EVO392FLTU
EVO392FLTU DISCONTINUO
3100K

Photo Gallery

EVO392FLDY
EVO392FLDY
EVO392FLDY
EVO392FLDY
EVO392FLDY

Specifications

LIGHT SOURCE
  • Source: 392x0,25W Warm White + Cold White LEDs
  • Source CCT: TU 3200K - DY 5600K
  • Luminous flux: TU 3600 lm - DY 3780
  • Lux: TU 1224lx @3 m
  • Lux: DY 1285lx @3 m
  • CRI: TU>92Ra, DY>92
  • Source life expectancy: > 50.000 h
OPTICS
  • Beam angle: 53°
COLOUR SYSTEM
  • Colour mixing: tunable white
  • CCT: CCT control through dedicated DMX channel
  • Macros: built-in white presets
DYNAMIC EFFECTS
  • Static mode: selection of static colour
  • Manual mode: manual adjustment of dimmer and strobe
CONTROL
  • Supported Protocols: DMX512
  • DMX channels: 1 / 2ch
  • Display: LED display user interface
ELECTRONICS
  • Dimmer: linear 0 - 100% electronic dimmer
  • Dimmer curves: 4 selectable dimming modes available
CONNECTIONS
  • Power connection: Neutrik powerCON IN/OUT connectors
  • Signal connection: Amphenol XLR 3p IN/OUT connectors
ELECTRICAL
  • Mains power supply: 100-240V - 50/60Hz
  • Max power consumption (230V): 105W
  • Output (at 230V): 20 units on a single power line
PHYSICAL
  • IP rating: IP20
  • Cooling: fan-free with natural convection
  • Housing: Sturdy aluminium profile
  • Finish: black
  • Operating temperature: Ta -10 to +45 °C (+14 to +113 °F)
  • Dimensions (WxHxD): 557x372x98 mm / 21.93''x14.65''x3.86''
  • Weight: 7kg / 15.43lbs
INSTALLATION
  • Suspension and fixing: bracket for hanging and positioning

Accessories & Related Products

(Optional) EVO392BD

Barndoor with 4 directional flaps to adjust the light beam, for EVO392FL

Order Code: EVO392BD

Downloads

Technical documentation and support files

User manual User manual

File name File size Download
User manualEvo392fl_USER_MANUAL_ITEN.pdf(21/11/2012)4MB
