MOSAICOLC5M

Mosaico LC5M

NEW
5 YEARS WARRANTY

Order Code: MOSAICOLC5M

Source
300W high-power white LED
Zoom range
7°- 49° motorised linear zoom
IP rating
 IP66 for outdoor installations
Weight
25kg / 55.12lbs

Key Features

  • IP66 for long-lasting installations, with minimal maintenance needed
  • C5-M treatment for permanent exterior installation also in marine environment
  • 7°- 49° linear zoom system, for both near and long throw installation
  • 300W White LED engine (8,000K), with up to 11'700 lumen output
  • Extensive feature set including 7 colour-filters on wheel, 7 interchangeable rotating gobos, animation wheel and motorized framing shutters

The Mosaico L is a bright outdoor LED image projector, designed for long-range image, textures and logo projections.
Built in a durable IP66 die-cast housing and painted with a C5-M marine treatment, it is ideal for outdoor use in challenging saline environments or near the sea, the Mosaico L offers a phenomenal output of 11,700 lumens and an extensive set of features including a rotating animation wheel, 7 interchangeable gobos, and motorized framing shutters that precisely focus within a certain projection area.
It has an exceptional zoom range, from 7° to 49°, making it versatile in both near-field and long-throw installations, or even for static and animated facade building lighting.

Read less
The Mosaico L is a bright outdoor LED image projector, designed for long-range image, textures and logo projections.Built in a durable IP66 die-cast housing and painted with a C5-M marine treatment, i...

Product Video

Discover the Mosaico LC5M in action

Photo Gallery

MOSAICOLC5M
MOSAICOLC5M
MOSAICOLC5M
MOSAICOLC5M

Specifications

LIGHT SOURCE
  • Source: 300W high-power white LED
  • CCT: 8.000
  • Luminous flux: (7°) 8'536 lm - (49°) 11'729 @Full
  • Lux: (7°) 28'230 lx - (49°) 867lx @5 m full
  • Source life expectancy: > 30.000 hrs (L70B10 @Ta 25° C / 77° F)
OPTICS
  • Zoom range: 7°- 49° motorised linear zoom
  • Lens diameter: 110mm / 4.33''
  • Lens type: HD anti-reflection lenses with achromatic coating
  • Focus: motorised
COLOUR SYSTEM
  • Colour mixing: cold white LED with colour wheel
  • Colour wheel: open + 7 colour filters
DYNAMIC EFFECTS
  • Control Resolution: 16-bit dimmer
  • Shutter system: 4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete framing system
  • Animation wheel: magnetic interchangeable animation wheel with CW and CCW rotation
  • Rotating gobos: open + 7 rotating gobos + open, interchangeable, indexing
  • Gobo size (BW): outer: 26,9 mm - image: 23 mm
  • Gobo size (Color): outer: 26,9 mm - image: 20,5 mm
  • FX generator: shutter macros with adjustable speed
  • Circular prism: 3ff with bi-directional rotation, indexing
  • Frost: linear 0 - 100% frost filter
  • Special features: record scenes and create chases and shows throughout these scenes
BODY
  • Body: sturdy die-cast aluminium body, scratch resistant paint C5M (as standard)
  • Body colour: RAL 9006
  • Other: Inspectable cover window for gobos replacement and maintenance
CONTROL
  • Protocols: DMX512, RDM, CRMX
  • Stand Alone: Stand Alone programmer and playback
  • DMX channels: 22 / 32 / 43channel
  • Wireless Control: Included LumenRadio Timo Fx DMX/RDM receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
  • RDM: RDM for remote monitoring and settings
  • Display: Graphic User Interface
  • Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
ELECTRONICS
  • Dimmer: linear 0 ~ 100% electronic dimmer
  • Dimmer curves: 4 selectable dimming modes available
  • Strobe / shutter: 1~30 Hz, electronic
  • Display battery: self-charging battery backup
  • Operating temperature: -20° C / +45° C (-4° F / +113° F) Ta
  • LED Control: flicker free frequency with adjustable PWM
  • Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
  • Mains power supply: 100-240V - 50/60Hz
  • Max power consumption: 440W
  • Standby power: 58 W
  • Output (at 230V): 6 units on a single power line
  • Power factor: > 0,98
PHYSICAL
  • IP rating: IP66 for outdoor installations
  • IK rating: 09
  • Cooling: combination of heat pipe cooling system and low noise fan
  • Suspension and fixing: bracket for hanging and positioning
  • Adaptors: XLR and BARE END 16A adaptors included
  • Signal connection: 1,8 m moulded IP signal IN/OUT connectors
  • Data connection: W-DMX transreceiver
  • Power connection: 1,8 m moulded IP power IN/OUT connectors
  • Dimensions (WxHxD): 362x428x451mm / 14.25''x16.85''x17.76''
  • Weight: 25kg / 55.12lbs
CERTIFICATIONS / APPROVALS
  • Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC
BOX CONTENT
  • 1 x MOSAICOLC5M
  • 1 x 0,28 meters 3G1mmq power cable (BARE END - IP connection adapter)
  • 1 x 5p XLR - IP connection female adapter
  • 1 x 5p XLR - IP connection male adapter
  • User Manual

Accessories & Related Products

Optional <b>Æther</b> Link

IP66 rated 1 Universe CRMX wireless transceiver for permanent outdoor installation

Order Code: AETHERLINK

Optional AWEXDC1221ADP

Signal adapter kit from AWEXDC1 series to AWEXDC2 series and vice versa

Order Code: AWEXDC1221ADP

Optional AWEXAC12ADP

Power adapter from AWEXAC1 cable series to AWEXAC2 cable series

Order Code: AWEXAC12ADP

Optional MOSLCCW2

Optional color wheel 2 for MOSAICOL

Order Code: MOSLCCW2

Optional MOSLCCW1

Optional color wheel 1 for MOSAICOL

Order Code: MOSLCCW1

Optional GBVMAP001

Gobo Mapping, F size, black and white (gobo holder included)

Order Code: GBVMAP00123F00

Optional FCLMOSAICOL

Flightcase for 2 pcs of MOSAICOL

Order Code: FCLMOSAICOL

Optional MOSBRACK

Order Code: MOSBRACK

Optional AWEXDC1L03

IP67 DMX extension cable for outdoor architectural projectors, L.03 m

Order Code: AWEXDC1L03

Optional AWEXDC1L05

IP67 DMX extension cable for outdoor architectural projectors, L.05 m

Order Code: AWEXDC1L05

Optional AWEXDC1L10

IP67 DMX extension cable for outdoor architectural projectors, L.10 m

Order Code: AWEXDC1L10

Optional AWEXDC1L20

IP67 DMX extension cable for outdoor architectural projectors, L.20 m

Order Code: AWEXDC1L20

Optional AWEXAC1L03

IP67 power extension cable for outdoor architectural projectors, L.03 m

Order Code: AWEXAC1L03

Optional AWEXAC1L05

IP67 power extension cable for outdoor architectural projectors, L.05 m

Order Code: AWEXAC1L05

Optional AWEXAC1L10

IP67 power extension cable for outdoor architectural projectors, L.10 m

Order Code: AWEXAC1L10

Optional AWEXAC1L20

IP67 power extension cable for outdoor architectural projectors, L.2 0m

Order Code: AWEXAC1L20

Optional UPBOXPRO

Firmware uploader kit, USB IN, 5-pin XLR DMX OUT connector

Order Code: UPBOXPRO

Optional RSR1235B

Steel security cable for hanging bodies, inox steel shackle, L=120 cm, black

Order Code: RSR1235B

Optional C6002B

Slim aluminum clamp, 200kg loading, 48-51mm tubes, M10 bolt, Black&White& White

Order Code: C6002B

Downloads

Technical documentation and support files

Data sheet & specs Data sheet & specs

File name File size Download
Letter datasheetMosaicolc5m_LETTER_DATASHEET_(EN).pdf(27/08/2025)436KB
Letter datasheetMosaicolc5m_A4_DATASHEET_(ITA).pdf(27/08/2025)432KB
Letter datasheetMosaicolc5m_A4_DATASHEET_(EN).pdf(27/08/2025)432KB
Tender SpecificationMosaicolc5m_TENDER_SPECIFICATION.pdf(17/01/2023)4MB

User manual User manual

File name File size Download
User manualMosaicolc5m_USER_MANUAL_EN.pdf(25/10/2024)7MB
User manualMosaicolc5m_Gobo_mapping_with_Mosaico_seri.pdf(20/02/2024)5MB
User manualMosaicolc5m_Wireless_Protocol_Compatibilit_EN.pdf(12/06/2023)4MB
User manualMosaico_series_custom_gobo_assembly_procedure.pdf(11/06/2025)476KB

DMX chart & personalities DMX chart & personalities

File name File size Download
DMX chartMosaicolc5m_DMX_CHARTS.pdf(16/10/2023)174KB

Photometrics Photometrics

File name File size Download
IESprolights_mosaicol_ies files.zip(22/02/2022)5KB
LDTprolights_mosaicol_ldt files.zip(22/02/2022)3KB
PhotometricsMosaicolc5m_PHOTOMETRICS_REPORT.pdf(22/02/2022)2MB
DialuxDownload DIALux product catalogue-

CAD symbols & drawings CAD symbols & drawings

File name File size Download
3D SKPMosaicolc5m_3D.skp(11/02/2022)276KB
2D cad symbolsMosaicolc5m_CAD_2DSYMBOLS.dwg(11/02/2022)53KB
3DMosaicolc5m_CAD_3D.dwg(11/02/2022)524KB
2DMosaicolc5m_CAD_2D.dwg(08/03/2022)3MB
Technical drawingMosaicolc5m_TECHNICAL_DRAWING.pdf(08/03/2022)207KB
VectorWorksVECTORWORKS_SYMBOLS.vwx(11/02/2022)422KB

Tech docs Tech docs

File name File size Download
Color DocumentMosaicolc5m_COLOR.pdf(08/03/2022)451KB
General safety infoMosaicolc5m_GOBO-MAPPING-DESIGN.pdf(12/04/2023)236KB
General safety infoMosaicolc5m_A4_GOBOS_CUSTOM_GUIDELINES(EN).pdf(03/06/2025)5MB
General safety infoMosaicolc5m_A4_GOBOS_CUSTOM_GUIDELINES(IT).pdf(03/06/2025)5MB
Gobos DocumentMosaicolc5m_GOBOS.pdf(08/03/2022)934KB
Noise ReportMosaicolc5m_NOISE_REPORT.pdf(05/07/2024)590KB
